Class A/B High Power MOSFET Amplifier

MOSFET power supply
Thermal protection
Overload protection
Short connection and DC offset Protection
2 Ohm stable
THD at rated power : 0.05%
High / Low level Input
Signal -to-noise ratio 90dB
Bridging capability
Automatic power on/off and soft start
Low pass filter control
Treble / bass version are available
Different colors of heat sink available
Protection light / power-on LED

POWER OUTPUT
DCA-3440 : RMS power 40W x 2ch;
Low-pass frequency control
Heat Sink Dimensions: 252 x 56 x 160 mm

DCA-3454: RMS power 50W x 4ch;
Low-pass frequency control
Heat Sink Dimensions: 252 x 56 x 320 mm

DCA-3460T/B : RMS power 60W x 2ch;
Subwoofer switch and treble/bass frequency control
Heat Sink Dimensions: 252 x 56 x 230 mm

DCA-3480T/B : RMS power 80W x 2ch;
Subwoofer switch and treble/bass frequency control
Heat Sink Dimensions: 252 x 56 x 260 mm

DCA-3410T/B : RMS power 100W x 2ch;
Subwoofer switch and treble/bass frequency control
Heat Sink Dimensions: 252 x 56 x 300 mm

• Place of Origin:
• P.R.C
• Packing:
• Gift Box Packing 4pcs per each export carton
