IR CONTROLLED 2-ZONE COMPACT ALARM & DOOR STRIKE ACTUATOR

RPS-303 is an IR controlled Compact Alarm and Door Strike Actuator designed to enhance the existing door access control system to incorporate alarm function and remote door strike control. It can also work independently as a compact alarm system. The alarm section comes with one N.C. Delay and one N.C. Instant protection zones. The door strike actuation section gives negative going momentary output to trigger the Egress Input of the keypad or the timer power pack for door strike.
The RPS-303 is compatible with all the �Protect-ON? and �AEI? keypads & timer power packs. RPS-303 is designed for in-door installation.

FEATURES :
� IR Remote Arm-Disarm Control with 6,561 Address Codes
� Two Independent N.C. Protection Zones of Instant & Delay
� IR Remote Control Door Strike Actuator
� IR Remote Keys Incorporate of Panic Button Function
� Built-in Piezo Siren with 110DB Sound Output
� On Board LED Indicators Showing Operation Status
� 60 Seconds Exit Delay, 30 Seconds Entry Delay & 3 Minutes Siren Timers
� 12V ? 16V DC Operation, 4mA Standby Current
� Each Set Comes with 2 IR Control Keys
� 8 Metres Control Distance
� Dimensions: (a) Main Unit -- 55(H) X 85(W) X 33(D) mm; (b) IR Key -- 56(H) X 36(W) X 15.4(D) mm
� Weight: (a) Main Unit - 110g; (b) IR Key - 20g
