824-2500mhz 8dbi Omni Camouflage Antenna

Model OF825G8 Frequency 824-960 MHz, 1710-2500MHz Polarization Vertical Horizontal Beam Width 360 deg Vertical Beam Width 30 deg (824-960MHz) 18 deg (1710-2500MHz) Gain 6 dBi (824-960MHz) 8 dBi (1710-2500MHz) VSWR 1.4 : 1 Electrical Downtilt 8-15deg Intermodulation IM3 -107 dBm Max Power 50 W Impedance 50 Ω Mechanical Specification Radome Material Fiberglass Radiator Copper Lightning Protection Direct Ground Connector N-female or 7/16 DIN- female Weight 6.8 kg Size 80x1900mm Mount Pole Diameter 40-80mm Wind Loading (Frontal) 60m/s
