Ws-6902 Digital Satellite Meter & Spectrum Analyzer

Ws-6902 Digital Satellite Meter & Spectrum Analyzer, WS-6902
Item Code / Model Number:
WS-6902

Ws-6902 Digital Satellite Meter & Spectrum Analyzer Ws-6902 Digital Satellite Meter & Spectrum Analyzer
WS-6902
DIGITAL SATELLITE METER
SATELLITE METER & SPECTRUM ANALYZER
Main Function:
3.5 Inch High definition TFT LCD Screen which Can show live Channels
NEC Solution
Shows both S/N and C/N
Shows strength and quality readings
Sound and Light Alarm When Lock Signal
Shows channel picture
Show numerical reading and bar reading
Digital Meter for Signal Strength(in numerical & #118alue and picture)
Easy Satellite Manager ( EDIT, delete and SCAN)
Edit TP, Frequency, LNB switch, Symbol Rate etc.
Completely programmable by the user
Input Frequency 950-2150MHz
Input Level -65-25dBm
Input Impedance 75(ohm)
Auto Calculate Angle of AZ ,EL
Upgrade S/W by PC
Easy to carry, size only 9.5cm X 15.5cm X 4.5cm
DisEqC Control
22KHz Control
Fast Charge LI-ION Battery(1950mAh), Can Last 4 Hours
Indicator Lights for 13/18 volts
Indicator lights for 22 KHz
USB port for software upgrades
USB software upgrade cable included
Neck strap includes
Carrying case included
12VDC power charger included
For the first time in a economical digital meter, you are now able to view the actual channel on the screen of the meter. Now you can quickly and accurately align the satellite AND you can instantly check the stability of the channel right on the screen of the meter. Transponders, Frequency, Symbol Rate, Polarity, and other settings can be modified by the user. There is never a need to send your meter in for a upgrade.
Meter never needs to be returned for re-calibration due to the unique calibration system built in to the meter. Each time the meter boots up it automatically calibrates for optimum performance so you can align each install with confidence.
Technical Parameter:
System capabilities Fully DVB compliant Yes
LNB/Tuner input Connector F type,male
Frequency range 950MHz-2150MHz
Signal lever -65dBm~-25dBm
LNB supply 13/18V,max400mA
LNB switch control 22KHz
DiSEqC Ver 1.0
Demodulator Front end QPSK
Symbol rate 2Mbps~45Mbps
SCPC and MCPC Capable Yes
Spectral inversion Auto conversion
System resource Processor 32bit processor (200MHz)
SDRAM 16Mbyte
FLASH 2Mbyte
EEPROM 8Kbyte
Video decoder MPEG 2 Main Proflie@Main Level
Data Rate up to 15M bits/s
Resolution 720*576,720*480
Video format PAL/NTSC/SECAM
MPEG Audio MPEG 1 layer 1&2
Type Mono
Sampling rates 32,44.1 and 48KHz
Serial data interface Connector USB type
Power supply Li-oN Battery 1950 mA
Supply voltage 12.6Volt
