Bazhou Dpair Power Tools Factory

Non-conductive cable sock-Open ended cable sock

Non-conductive cable sock-Open ended cable sock, Non-conductive cable sock
Item Code / Model Number:
Non-conductive cable sock

Non-conductive cable sock-Open ended cable sock Non-conductive cable sock-Open ended cable sock
Non-conductive cable sock-Open ended cable sock
Pulling grip&Support grip&Cable grip& Pulling grip&Mesh pulling-grips are used for pulling overhead or underground cable, for stringing service or communications lines into buildings, for pulling wire through conduit, and for general underground construction. Cable socks-Single eye cable sock- Pulling grip
Pulling grips may be used for pulling bare or insulated wires, and wire rope. They install quickly and easily, and are designed to pass readily through ducts, conduit, blocks and sheaves.
Pulling grips are reusable and do not damage the cable because pulling tension remains uniform along the length of the grip. The mesh will fit either a single cable, or a bundle of cables. pulling grips are woven of galvanized steel - strong and long lasting.
There are three basic types of pulling grips, together with a choice of wire mesh types and lengths to meet a wide variety of pulling requirements: Snake Grips,Cable grip,Support grip- Cable grip

No. Applicable diameter Rated load Length
Scd-01 6-13mm 900 kg 300 mm
Scd-02 12-19mm 1590 kg 550 mm
Scd-03 19-25mm 2120 kg 600 mm
Scd-04 25-38mm 2560 kg 700 mm
Scd-05 7-12mm 300 kg 315 mm
Scd-06 13-18mm 400 kg 365 mm
Scd-07 18-24mm 600 kg 365 mm
Scd-08 25-35mm 700 kg 465 mm
Scd-09 35-48mm 1100 kg 535 mm
Scd-010 49-60mm 2000 kg 715 mm
Scd-011 60-75mm 2000 kg 830 mm
Scd-012 75-90mm 2500 kg 930 mm
Scd-013 90-115mm 2500 kg 1045 mm
Scd-014 110-135mm 3000 kg 1170 mm
