Sell Digital Display Pendulum Charpy Impact Tester + Impact Testing Machine

Application & Features:
They are mainly used to determine the anti-impact capability of metal materials under dynamic load. They are the best testing equipments for many metal material manufactories, quality inspection departments and universities. The results will be displayed on both digital screen and dial gauge. JB-S series impact testers can use pendulum's residual impact energy to achieve the re-raising of pendulum, so as to save energy. The results can be printed out, be applicable for mass testing departments.

Standards:
JB-S series impact testers are strictly designed according to the standards ASTM E23, ISO148-2006 and GB/T3038-2002, GB/229-2007.

Main Technical Specifications:
Specifications JB-300S JB-500S JB-800S
Impact energy (J) 150,300 250,500 500,800
Impact velocity (m/s) 5.2 5.4 5.9
Raised angle 150º
Standard span (mm) 40
Distance between pendulum rotating center and specimen center (mm) 750
Round angle of jaws (mm) R1-1.5
Round angle of striking edge (mm) R2-2.5
Size of specimen (mm) 10×10×55
Power supply 3phs, 380V, 50Hz,
Dimensions (mm) 2124×600×1340 2144×736×1390 2450×1200×2455
Net Weight (KG) 450 650 2300
Display LCD Monitor
