waste engine motor oil recycling machine

Because the waste oil contain too much contamination, including non-hydrocarbon, alkene, polycyclic aromatic hydrocarbon, metal hydronium, impurities, metal particles, asphaltene and colloid etc. and due to the traditional technology only can refine the waste oil to base oil, can’t use directly, so our company is researching the new technology about distilling machine, which can distill all kinds of waste oil into clean oil, easy to operation, and the lower operation cost.
Working principle
TY-2 Oil Recycling Equipment for Used Motor Oil adopt physicochemical actions to polymerize,passivate, absorb and eliminate impurities and harmful contamination. We research a new chemical alkaline complex catalyst, which can restore and regeneration the Waste oil to clean oil, save the component of the oil.

Process
It can convert used black mixed lube oil to yellow base oil.This is the most effective process for lube oil recycling , TY vacuum system is to refine waste oil in a batch process.Waste lube oil after pre-treatment ,will be pumped into a catalyst reactor we will add two kinds catalyst blend with oil and heat in a distillation kettle under vacuum. As the temperature in the kettle rises, various cuts are liberated and rise as vapors, to be condensed in a condenser. The condensed products are available as different products corresponding to various kettle temperatures .

Finally, the process ends when the residual material in the kettle does not vaporize, even at a temperature of around 350°Celsius. At this point, the heating in the distillation process is stopped and the process is essentially complete.

Using advanced vacuum distillation technology,which is different from the traditional sulfuric acid and the flocculation process. Traditional process uses sulfuric, water glass(Na2O.mSiO2 ,1%),TEPA(Tetraethylenepentamine)C8H23N5,1-2%) and activity clay(25%) to treat used motor oil. These additives are expensive and TEPA is very difficult to buy.

Advantages:
1.Low cost, cost is 30$ for refine one tons used motor oil
2.Easy to operate,low operation cost, only 1-2 workers can control the machine.
3.The machine can recycle gasoline motor oil, diesel motor oil, all kinds of engine oil, and other lubricant oil to clean oil.
4.Environmental friendly. This machine is full-enclosed, there is no any harmful smell come out form the machine, colloid, oxid, acid, pitch will be converted to oil sludge, can be use as bitumen and fuel.
5.85% high recycling rate. This includes 6-8% diesel and gasoline mixture,80-85% base oil and 8-10% oil sludge.
6.Efficient vacuum systems
7.High quality refined oil, no any discoloration caused by oxidation, no any bad smelling.
