PH7.62 Full Color Display for Indoor

PH7.62 Full Color Display for Indoor

PH7.62 Full Color Display for Indoor PH7.62 Full Color Display for Indoor
Type: PH7.62 SMD3528; Pixel Pitch: 7.62mm; Dimensions (W*H): 244mm*122mm; Resolution (W*H): 32*16; Pixel Density: 512dots/module; Pixel Density:17222 dots/sqm Brightness:≥1350 cd/sqm Viewing Distance:5- 100 m based on the pixel distance and your screen size. Drive Mode"1/8 scanning Continual Running Time:>72 Hours Life-span (typical use):100,000 Hours Average No Failure Time:>8,000 Hours Working Temperature:-20 to +50 Celsius degree Grey Scale:Recommend 4096 level (software adjustable from 2bit to 16bit) Power consumption:Average: 300W/㎡ Max: 800 W/㎡ Display Colors:64G(under 4096 level gray scale) Control Mode:Video frequency Synchronic control Color contrast ratio / temperature:1800:1 Symmetry of screen brightness:≥ 0.9 (low brightness/high brightness) Surface Flatness:screen surface: +/- 1mm, difference between modules: 1mm Signal Interface:DVI (S-VIDEO, CVBS, VGA, PAL/NTSC, etc. thru. a video converter) Effective transmitting distance:Unshielded Twisted pair net line transmission distance100m, max 130m Multi mode optic fiber transmission distance 500m; Single mode one 10km Display Media:Text, Animation, Graphic, Video, etc. system Operating Platform:WINDOWS 98, WINDOWS 2000, WINDOWS XP, WIN7 LED display,outdoor LED video display,Indoor LED screen,stadium perimeter LED display,stage LED screen, the most professional manufacturer of LED Display
  • Place of Origin:
  • China
  • Brand:
  • RSB
  • Other Price Terms:
  • Negotiable
  • Payment Terms:
  • ;T/T
  • Min Order Quantity:
  • 1sqm
  • Standard / Certificates:
  • ce fcc iso9001

Company Profile

  • Business Type:
  • Manufacturer
  • Country:
  • China
  • Employee Count:
  • 150
  • Established Year:
  • 2012
  • Yearly Sales Volume:
  • US$1M - US$5M

Contact Information

  • Company Name:
  • Shenzhen RSBLED Electronic Co.,Ltd
  • Country:
  • China
  • Address:
  • Bldg A & C, RSB Tech Park, Fuying No.2 Industrial Park, Rd Jian'an, Fuyong, Shenzhen, China
  • Website:
  • http://www.rsbledsign.com
