Big Led Moving Head
Big Led Moving HeadItem Code / Model Number:
Big Led Moving Head
Product model:PRG-M108
Product name:Big LED moving head
TECHNICAL REFERENCE
1/3W LED
Voltage :90-240V. 50/60Hz
Power :150/380W
Light beads :1/3W*108(R27,G36,B36,W9)
Control Signal : sound control，auto mode,
Master/slave and DMX512 Channel ：15CH
Light beam Angle：15°，25°，30°，45°
Effects ：RGBW color mixture can achieve 167,000 kinds or more,
strobe and dimming function.
Display：2*16LCD plus four switch keys to choose menu function.
Pan scan:540 degree 8/16bit, Tilt scan：270 degree 8/16bit
CH1:Main dimming，CH2:red，CH3 green，CH4 blue，
CH5 white，CH6 Strobe speed，CH7 strobe effect ，
CH8 Macro function speed，CH9 Macro function ，
CH10 X axis，CH11 Y axis，CH12 X16bit，CH13 Y16bit，
CH14 XY speed，CH15 reset
NW：9.5Kg;
GW：11.5Kg
Packing Size ：380*360*455mm
Product name:Big LED moving head
TECHNICAL REFERENCE
1/3W LED
Voltage :90-240V. 50/60Hz
Power :150/380W
Light beads :1/3W*108(R27,G36,B36,W9)
Control Signal : sound control，auto mode,
Master/slave and DMX512 Channel ：15CH
Light beam Angle：15°，25°，30°，45°
Effects ：RGBW color mixture can achieve 167,000 kinds or more,
strobe and dimming function.
Display：2*16LCD plus four switch keys to choose menu function.
Pan scan:540 degree 8/16bit, Tilt scan：270 degree 8/16bit
CH1:Main dimming，CH2:red，CH3 green，CH4 blue，
CH5 white，CH6 Strobe speed，CH7 strobe effect ，
CH8 Macro function speed，CH9 Macro function ，
CH10 X axis，CH11 Y axis，CH12 X16bit，CH13 Y16bit，
CH14 XY speed，CH15 reset
NW：9.5Kg;
GW：11.5Kg
Packing Size ：380*360*455mm
- Place of Origin:
- China
- Brand:
- Progloballight
- Unit Price:
- USD 240
- Price Terms:
- EXW Guangzhou
- Packing:
- NWï¼9.5Kg; GWï¼11.5Kg Packing Size ï¼380*360*455mm
- Payment Terms:
- T/T;Cash
- Delivery Time:
- 7 days
- Min Order Quantity:
- 10pcs
- Standard / Certificates:
- CE
- Keywords:
- led moving head light, high power moving head lights, stagel ighting moving
