Sell Super Span Construction Cold Roll Forming Machinery from Yingkou Zhongxing Colored Steel Sheet Equipment Co., Ltd.

Sell Super Span Construction Cold Roll Forming Machinery

Continuous Selling Item

Sell Super Span Construction Cold Roll Forming Machinery

Description

Roll forming machine
The products from roll forming machine looks very beautiful and have a high strength, its widely used as the roof of the factory, garden, hotel, exhibition center, etc!
Main Technical Specification zx-240(610)
1. Size: 9300mmx2270mmx2400mm
2. Total Weight: About 12000kg
3. Controlling System: PLC
4. Forming Power: 7.5kw
5. Bending Power: 4.0kw+1.5kw+1.5kw
6. Cutting Power: 3.0kw
7. Material of rollers: 45#steel, quenched HRC 58-62
8. Material of roller shafts: 45#steel
9. Material of cutting blade: Cr12 steel
10. PLC Type: Siemens
11. Step of rollers: 13 steps
12. Feeding Width: 914mm
13. Effective Width: 610mm
14. Thickness of the coil: 0.6-1.6mm
15. The depth of the groove: 203mm
16. Working speed: Straight sheet: 15m/min
17. Arch sheet: 13m/min
18. Sewing: 10m/min
19. Max span: 38m

Place of Origin:
China
Brand:
Liaoning
Packing:
40HQ
Payment Terms:
L/C;T/T
Delivery Time:
0-15
Min Order Quantity:
1 set
Standard / Certificates:
CE Certification and ISO9001-2008 Quality Management system Certification.

Company Profile

Business Type:
Manufacturer
Country:
China
Employee Count:
50
Established Year:
2000
Yearly Sales Volume:
US$5M - US$10M
Principal Customers:
K Span Roll Forming Machine, Abm Super K Span Arch Plate Roll Forming Machine, K Span Mic Roll Forming Machine, Construction Machinery, Arch Roof Sheet Cold Roll Forming Machine
Focus Markets:
All Over The World
Certificates:
CE Certification and ISO9001-2008 Quality Management system Certification,Trade Mark

Contact Information

Company Name:
Yingkou Zhongxing Colored Steel Sheet Equipment Co., Ltd.
Country:
China
Address:
Zhanqian District, Yingkou City, Liaoning Province, China
Website:
http://www.zhongxing-china.cn
