Fiberglass Duct Rod
Fiberglass Duct Rod , 4.5 -17mmItem Code / Model Number:
4.5 -17mm
Fiberglass Duct Rod
Fiberglass Duct Rudders & Fish tapes
A high quality fiberglass rod, specially constructed to provide exceptionally high tensile strengths, whilst retaining flexibility. The 80% fill rate glass fiber core is reinforced with a high strength resin. A braided reinforcing wrap is added before the final polypropylene wear resistant protective coating is applied. The continuous rods range from 4.5mm to 16mm with lengths from 30m to 300m.
Features and Benefits:
Strong non-conductive fiberglass rod construction.
Rustproof bull-nose pulling eye.
For longer conduit runs and underground duct.
Rugged tubular steel reel with adjustable positioning.
Feed device allows rod to feed out or be wound back onto reel with easy push or pull of rod.
Many applications, both commercial and residential.
Splice kits and Repair Kits are available
Technical Data type EKH
100m/10mm type EKH
120m/10mm type EKH
150m/10mm
L x W x H (mm) 870mm×400mm×920mm
Weight (kg) 33kg 35kg 38kg
Min. Bend Radius mm 330 mm
Breaking Strength kg 4800 kg
A high quality fiberglass rod, specially constructed to provide exceptionally high tensile strengths, whilst retaining flexibility. The 80% fill rate glass fiber core is reinforced with a high strength resin. A braided reinforcing wrap is added before the final polypropylene wear resistant protective coating is applied. The continuous rods range from 4.5mm to 16mm with lengths from 30m to 300m.
Features and Benefits:
Strong non-conductive fiberglass rod construction.
Rustproof bull-nose pulling eye.
For longer conduit runs and underground duct.
Rugged tubular steel reel with adjustable positioning.
Feed device allows rod to feed out or be wound back onto reel with easy push or pull of rod.
Many applications, both commercial and residential.
Splice kits and Repair Kits are available
Technical Data type EKH
100m/10mm type EKH
120m/10mm type EKH
150m/10mm
L x W x H (mm) 870mm×400mm×920mm
Weight (kg) 33kg 35kg 38kg
Min. Bend Radius mm 330 mm
Breaking Strength kg 4800 kg
- Place of Origin:
- China
- Brand:
- De Li
- Unit Price:
- USD 200
- Price Terms:
- FOB Tianjin
- Packing:
- hard paper, wooden case
- Payment Terms:
- T/T
- Delivery Time:
- 5 days
- Min Order Quantity:
- 1000meters
- Keywords:
- fiberglass
