Sell p6mm
Sell p6mmContinuous Selling Item
Sell p6mm
List Item Description 1 Pixel Pitch 6mm 2 Module Size 192*96mm 3 Pixel Density 27777/㎡ 4 Pixel composition 1R1G1B 5 LED Type SMD0805 6 Module Resolution 32*32 7 Power Consumption of Module 22W 8 The Optimum Viewing Distance 6m 9 The Optimum Viewing Angle 160°/120° 10 Maximum Power Consumption 1400W/㎡ 11 Cabinet Size 768*576mm 12 Cabinet Resolution 128*96 12 Cabinet Weight 30Kg 14 Driving IC MBI5026GF 15 Driving Method 1/8 Scan Constant Current Driving 16 Frame Frequency ≥60Hz/s 17 Refresh Rate ≥360Hz/s 18 White Balance Luminance(CD/㎡) ≥1500cd/㎡ 19 Operating Environment Temperature -20℃—60℃ Optional 20 Operating Voltage 220V±10% or 110V±10% 21 Grey Scale Display Colors≥16.7M(Synchronized) 22 Brightness Adjustment 256 grades of each color(R.G.B)can be adjusted manually and 8 levels of each color can be adjusted automatically 23 Input Signal RF、S-Video RF, S-Vido, RGB, RGBHV, YUV etc. 24 Control System PCTV non-liner editting card+DVI display card+main control card+optic fiber transmission(Optional) or video dealer 25 Average No Failure Time >5000 hours 26 Life-span >100000 hours 27 Out-of Control rate <0.0001 28 Transmiting Distance Internet cable: 100m, the distance will add 100m if add one signal collector. Optic fiber: ≤20Km(single module),≤500m(modules)
- Place of Origin:
- shenzhen
- Brand:
- Lucky
- Payment Terms:
- ;T/T
- Delivery Time:
- 20-25
- Min Order Quantity:
- 1sqm.
- Standard / Certificates:
- CE.ROHS,ISO9001:2000
