Beer Keg Washing, Filling Unit
Beer Keg Washing, Filling Unit,Item Code / Model Number:
Beer Keg Washing, Filling Unit
Features:
A The process of washing, sterilizing, filling is finished automatically.
B Filling volume is controlled by high-speed positioning filling skill system
C The temperature of hot water and lye is controlled automatically.
D Available to connect more than one machine together to reduce the investment.
E Auto washing of the beer pipeline CIP
F Figure statistics and display function
G Check keg spear automatically, make sure the washing quality and filling volume.
H Suitable for different beer keg sizes.
Working Procedures
Location—scavenge wine remains—mixed hot mater washing—blow -- sterilize by lye—recycle—hot water washing—recycle—sterilize by steam—sterile water washing—recycle—Preparation of CO2 pressure --filling
Technical parameters:
Siemens LOGO PLC
Stainless steal control crow valve
Pneumatical component of Taiwan Yadake
Main Parameter
Filling accuracy: 5‰
Capacity: 30-40bottles/hour
Compressed air: pressure>0.4Mpa
Wince resource pressure: 0.25~0.4Mpa
Power: AC220V
Voltage: DC24V
Equipment size: 900mm x1530mm x1950mm
A The process of washing, sterilizing, filling is finished automatically.
B Filling volume is controlled by high-speed positioning filling skill system
C The temperature of hot water and lye is controlled automatically.
D Available to connect more than one machine together to reduce the investment.
E Auto washing of the beer pipeline CIP
F Figure statistics and display function
G Check keg spear automatically, make sure the washing quality and filling volume.
H Suitable for different beer keg sizes.
Working Procedures
Location—scavenge wine remains—mixed hot mater washing—blow -- sterilize by lye—recycle—hot water washing—recycle—sterilize by steam—sterile water washing—recycle—Preparation of CO2 pressure --filling
Technical parameters:
Siemens LOGO PLC
Stainless steal control crow valve
Pneumatical component of Taiwan Yadake
Main Parameter
Filling accuracy: 5‰
Capacity: 30-40bottles/hour
Compressed air: pressure>0.4Mpa
Wince resource pressure: 0.25~0.4Mpa
Power: AC220V
Voltage: DC24V
Equipment size: 900mm x1530mm x1950mm
