1. Techonlogy specification
Model QX-1
Size of plate form 510mm×1170mm
Height of the plate form 660mm
Size of the machine 1250mm×1250mm×2050mm
The maximum stroke of the stopcock 300mm
Net weight 180kg
Capacity 90-120keg/h（20L）
Air consumption 8-22.5m3/h (20L)
Water consumption 1-3 m3/h (20L)
Power 950w
Washing type inversion
The barrel size Ф250mm-ф500mm H:400mm-660mm

2. Technology parameter
Pressure of the air 0.6-0.8Mpa
Pressure of the cylinder 0.4-0.5 Mpa
Pressure of the CO2 0.2-0.3Mpa
Pressure of the steam 0.2 Mpa
Voltage of the electric power AC 220V 50HZ
3. The main framework
Frame , control system, solenoid pilot actuated valve, pneumatic element, water flow system etc.
4. Features
This is the cleaning machine of QX-1, the capacity is 120 barrels per hour .
It is mainly used in cleaning the plastic beer barrel by the water and the sterile water ,equipped with the function of CO2 prepare press
