1 Watt High Power Led

model color angle（°） wavelengthcolor temperature (IF=350mA) flux
(IF=350mA) Forward voltage (IF=350mA)

Minimum max Minimum max Minimum max
NG-P001L4M03 red 140±5 620nm 625nm 15 40 1.9 2.4
NG-P001L4N03 red 140±5 625nm 630nm 15 40 1.9 2.4
NG-P001L4K03 yellow 140±5 585nm 590nm 15 35 1.9 2.4
NG-P001L4L03 yellow 140±5 590nm 595nm 15 35 1.9 2.4
NG-P001L4B02 blue 140±5 450nm 455nm 15 20 3 3.4
NG-P001L4C02 blue 140±5 455nm 460nm 15 20 3 3.4
NG-P001L4D02 blue 140±5 460nm 465nm 15 25 3 3.4
NG-P001L4E02 blue 140±5 465nm 470nm 15 25 3 3.4
NG-P001L4F05 green 140±5 510nm 515nm 40 80 3 3.4
NG-P001L4F05 green 140±5 515nm 520nm 40 80 3 3.4
NG-P001L4F05 green 140±5 520nm 525nm 40 80 3 3.4
NG-P001L4G05 green 140±5 525nm 530nm 40 80 3 3.4
NG-P001L4O08 white 140±5 2000K 3000K 70 80 3 3.4
NG-P001L4Q09 white 140±5 3000K 4000K 80 90 3 3.4
NG-P001L4S10 white 140±5 4000K 5000K 90 100 3 3.4
NG-P001L4U10 white 140±5 5000K 6000K 90 100 3 3.4
NG-P001L4W10 white 140±5 6000K 7000K 90 100 3 3.4
NG-P001L4Y10 white 140±5 7000K 8000K 90 100 3 3.4
NG-P001L4Z10 white 140±5 8000K 9000K 90 100 3 3.4
