Bag Making Machine Cw-800njt

CW-800NJT fully automatic high-speed inside glue patch handle carrier bag making machine (spare parts)
Main Parameter:
Model CW-800NJT
Orientation from right to left
Width of Unwinding 750mm (two layer)
1600(single layer with folding triangle)
Diameter of Unwinding ф1000mm
Length of bag making 300-750mm
Width of bag making 200-650mm
Top folding size 95mm
Bottom gusset: 30-60mm
The thickness of film HDPE 0.03-0.06mm
LDPE 0.04-0.1mm
width of patch film 140mm
Thickness of patch film HDPE 0.08-0.15mm（single layer）
Max.diameter of the patch film roll ф500mm
Feeding speed: 50m/min
Machine speed: 150 times/min
Speed of bag making 80-120pcs/min
Total power 13KW
Voltage of power supply 380V 50HZ
Working Sound 90db
Dimension of machine 11000X3200X2050mm
Weight of machine 3000KG

The condition of machine running:
A. illumination less than 3000LX
B. altitude less than 1000m
C. The temperature around the machine between +40℃and -20℃.
D. The relative humidity of air less than 85%.
E. Without conductive dust.
F. Without blast danger and fire.
G. Working Air compressor 7.5 HP
