SMD electrolytic capacitors 0.1~1500uF
SMD electrolytic capacitors 0.1~1500uF, AECS seriesItem Code / Model Number:
AECS series
SMD electrolytic capacitors 0.1~1500uF
SMD electrolytic capacitor
Surface mount type
AECSeries:
1.Features
● Endurance: 85 °C 2000 hours
● Reflow soldering and reliability
● Vibration-proof product is available upon request
● RoHS directive compliant
● High stability and reliablity.
2. Specifications
Category Temp. Range : –40 °C to +85 °C
Rated W.V. Range : 4V.DC to 100 V.DC
Nominal Cap. Range : 0.1μF to 1500 μF
Capacitance Tolerance : ±20 % (120 Hz/+20 °C)
Rated capacitance range : 0.1uF ,0.22uF,0.33uF,0.47Uf,1.0uF,2.2uF,3.3uF,4.7uF,10uF,22Uf,33uF,47Uf,68uF,100uF,150uF,220uF,330uF,470uF,680uF,
1000uF,1500uF.
Rated voltage range : 4V ,6.3v,10V,16V,25V,35V,50V,63V,100V .
3.Applications:
● Designed for surface mounting on high density PC board.
● Applicable to automatic mounting machine fed with carrier tape.
Surface mount type
AECSeries:
1.Features
● Endurance: 85 °C 2000 hours
● Reflow soldering and reliability
● Vibration-proof product is available upon request
● RoHS directive compliant
● High stability and reliablity.
2. Specifications
Category Temp. Range : –40 °C to +85 °C
Rated W.V. Range : 4V.DC to 100 V.DC
Nominal Cap. Range : 0.1μF to 1500 μF
Capacitance Tolerance : ±20 % (120 Hz/+20 °C)
Rated capacitance range : 0.1uF ,0.22uF,0.33uF,0.47Uf,1.0uF,2.2uF,3.3uF,4.7uF,10uF,22Uf,33uF,47Uf,68uF,100uF,150uF,220uF,330uF,470uF,680uF,
1000uF,1500uF.
Rated voltage range : 4V ,6.3v,10V,16V,25V,35V,50V,63V,100V .
3.Applications:
● Designed for surface mounting on high density PC board.
● Applicable to automatic mounting machine fed with carrier tape.
- Place of Origin:
- China mainland
- Brand:
- Pluspark
- Unit Price:
- USD 0.0002
- Price Terms:
- EXW Shanghai
- Packing:
- Tape , Reel package
- Payment Terms:
- L/C;T/T;Cash
- Delivery Time:
- 7 days
- Min Order Quantity:
- 2000pcs
- Standard / Certificates:
- CQC,EN-EC ,UL/CUL
- Keywords:
- smd electrolytic capacitor, capacitor, electrolytic capacitor
