Fusion Splicer Pt-660
Fusion Splicer Pt-660, 1Item Code / Model Number:
1
Fusion Splicer Pt-660
Features
Color LCD monitor and 256x magnification
Compact and lightweight
Reversible monitor with control panel on each side
Maximum wind velocity: 15m/s
8sec splice time, 40sec tube-heat time
Simultaneous X and Y views
Large capacity internal battery
System test: ensures the best working condition
User programmable
Auto check fiber end face
Auto calibrate parameters
Store 8,000 groups of splice results
Multiple language options
Specification
Model Pt-730
Applicable fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655)
Fiber cleaved length 12-16mm(Coating diameter:250um)
16mm(Coating diameter: 250 -1000um)
Fiber diameter Cladding diameter:80 -150um
Coating diameter:100- 1000um
Fiber Count Single
Fiber aligning method Core or clad aligning
Image processing method Digital
Actual average splice loss 0.02dB (SM), 0.01dB (MM),
0.04dB (DS), 0.04dB( NZDS)
Splicing time Typical 8 sec,with standard SM fiber
Splicing mode 53(templet), 40(user)
Splice loss estimate More accurate
Return loss >60dB
Storage of splice result 4000 results,20 parameter per result
Fiber display and magnification 300X(X or Y view),150X(X and Y view)
Tube heating time Typical 30 sec
Tube heating mode 8(templet), 24(user)
Tube heating temperature Can be adjusted
Applicable Protection sleeve length 60mm, 40mm and a series of micro sleeves
Tension test 2N
Electrode life 2500
No.of splice/heating with battery Typical 150 cycles (splice/tube heat) with inner Li-battery
Display screen 5 inch color LCD monitor
Image change over The fiber image is turned upside down
Terminals USB 1.1 and VGA
Operating condition 0 - 5000m above sea level, 0 - 95%RH and -10-50*, respectively, Max. wind velocity of 15m/s
Power supply AC 100-240V with AC adapter; inner Li-battery(6600mAH)
Dimensions 170mm(L) x170mm (W) x140mm (H)
Weight 2.7 Kg excluding battery,3.3 Kg including battery
Color LCD monitor and 256x magnification
Compact and lightweight
Reversible monitor with control panel on each side
Maximum wind velocity: 15m/s
8sec splice time, 40sec tube-heat time
Simultaneous X and Y views
Large capacity internal battery
System test: ensures the best working condition
User programmable
Auto check fiber end face
Auto calibrate parameters
Store 8,000 groups of splice results
Multiple language options
Specification
Model Pt-730
Applicable fibers SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655)
Fiber cleaved length 12-16mm(Coating diameter:250um)
16mm(Coating diameter: 250 -1000um)
Fiber diameter Cladding diameter:80 -150um
Coating diameter:100- 1000um
Fiber Count Single
Fiber aligning method Core or clad aligning
Image processing method Digital
Actual average splice loss 0.02dB (SM), 0.01dB (MM),
0.04dB (DS), 0.04dB( NZDS)
Splicing time Typical 8 sec,with standard SM fiber
Splicing mode 53(templet), 40(user)
Splice loss estimate More accurate
Return loss >60dB
Storage of splice result 4000 results,20 parameter per result
Fiber display and magnification 300X(X or Y view),150X(X and Y view)
Tube heating time Typical 30 sec
Tube heating mode 8(templet), 24(user)
Tube heating temperature Can be adjusted
Applicable Protection sleeve length 60mm, 40mm and a series of micro sleeves
Tension test 2N
Electrode life 2500
No.of splice/heating with battery Typical 150 cycles (splice/tube heat) with inner Li-battery
Display screen 5 inch color LCD monitor
Image change over The fiber image is turned upside down
Terminals USB 1.1 and VGA
Operating condition 0 - 5000m above sea level, 0 - 95%RH and -10-50*, respectively, Max. wind velocity of 15m/s
Power supply AC 100-240V with AC adapter; inner Li-battery(6600mAH)
Dimensions 170mm(L) x170mm (W) x140mm (H)
Weight 2.7 Kg excluding battery,3.3 Kg including battery
- Place of Origin:
- China
- Brand:
- Optecfiber
- Unit Price:
- USD 3400
- Price Terms:
- FOB Shanghai
- Packing:
- carrying case
- Payment Terms:
- T/T
- Delivery Time:
- 2 days
- Min Order Quantity:
- 1 set
- Standard / Certificates:
- ISO9001
- Keywords:
- splicing machine, optical fusion splicer, fibre splicer
