Sx-80 The State-of-the-art Digital Spring Coiling Machine

SX-80 The State-of-the-art Digital Spring Coiling Machine produces Bonell springs for mattress at speeds of 80 pcs/min. In a single cycle,the wire is coiled to a spring, knotted at both ends, heat treated and to be collected to an outlet channel. The coiler SX-80 utilized a fully integrated computerized Programmable Logic Controller (PLC) and Servo control system. All machine functions include wire feeding length, heat treatment,lubrication and self-protecting are automatically controlled.
Technical Data
Spring Type Bonell
Capacity 80 PCS/MIN
Spring End Ring Φ62-Φ95MM
Steel Wire Gauge Φ1.8-Φ2.4MM
Spring Height 80-190MM (Option: 190-210MM)
Convolutions 4-7 Turns
Main Drive Power 4KVA
Swift Frame Power 2.2KVA
Heat Teatment 10KVA
Weight Net Approx:2730KG
Power Requirement 380V,3 Phase,50-60HZ
(Option:415V-480V,220V)
