Wuhan Changxin Science&technology Development Co., Ltd

Laser Welding Machine

Laser Welding Machine, cxw300
Item Code / Model Number:
cxw300

Laser Welding Machine Laser Welding Machine
Product Features
Accord with Europe CE standard
The output power is high and stable
It is convenient to adjust the height of two dimensional working table and rotary attachment and deflect the incident angle of laser beam
the two dimensional working table and rotary attachment could be controlled by IPC or PLC
Widely used in many industries
Technical Parameters
Model of Machine CXW300
Table Duration 150×150mm
Laser Maximum Output Power 300 W
Pulse Width 0.1-20 ms
Pulse Frequency 1-150 Hz
Energy Instability ± 3%, the single pulse energy ≥ 60 J
Spot Diameter 0.3-0.6 mm
Laser Wavelength 1064nm
Current Work 100-450 A
Working Power 380V ± 10% / 50Hz
Laser Wavelength 1064nm
Applicable Industries or materials
Widely used to weld the materials in aircraft, airspace, weapons, naval vessel, petrochemical, electric appliance, medical, instrument, electronical , motor, and mould industries. The metal and their alloyed materials like gold, silver, platinum, stainless steel, titanium etc are all applicable.
Package: wooden case
The working area and laser power can be customized according to requirement
  • Place of Origin:
  • China
  • Brand:
  • changxin
  • Unit Price:
  • USD 29999
  • Price Terms:
  • FOB shanghai
  • Other Price Terms:
  • T/T
  • Packing:
  • WOODEN CASE
  • Payment Terms:
  • T/T
  • Delivery Time:
  • with 20-30working days days
  • Min Order Quantity:
  • 1 set
  • Standard / Certificates:
  • CE
  • Keywords:
  • laser, welding, machine

Company Profile

  • Business Type:
  • Manufacturer
  • Country:
  • China
  • Employee Count:
  • 56
  • Established Year:
  • 2006
  • Yearly Sales Volume:
  • US$5M - US$10M

Contact Information

  • Company Name:
  • Wuhan Changxin Science&technology Development Co., Ltd
  • Country:
  • China
  • Address:
  • No.7 Jiangjun 5th Road, Dongxihu District, Wuhan City, Hubei Province, China
  • Website:
  • http://www.cxlaser.cn/en
