Heat Pump

Specification
Model(House Series) 040-B-(H)C(N) 050-B-(H)C(N) 060-B-(H)C(N) 080-B-(H)C(N) 080SB-(H)C(N)
Heating capacity kw 13.0 15.0 17.0 25.0 25.0
BTU/h 44000 52000 60000 85000 85000
Cooling capacity kw 10.0 11.5 13.5 19.5 19.5
BTU/h 34000 39000 46000 67000 67000
COP 30/35 3.95 3.96 3.97 3.93 3.93
EER 2.86 2.87 2.88 2.83 2.83
Power supply V/Ph/Hz 230/1/50 230/1/50 230/1/50 230/1/50 380/3/50
Compressor Rotary*2 Rotary*2 Rotary*2 Rotary*3 Rotary*3
Net dimensions(L*W*H) mm 1100/440/1350 1350/515/1450
Shipping dimensions(L*W*H) mm 1180/510/1480 1430/580/1580
