forklift

1 Model 　 CPCD35W CPCD35

2 Power Type 　 Diesel Diesel

3 Rated Capacity kg 3500 3500
4 Load Centre mm 500 500
5 Lift Height mm 3000 3000
6 Fork Size L×W×T mm 1070×125×50 1070×125×50
7 Mast Tilt Angle F/R Deg 6°/12° 6°/12°
8 Front Overhang (Wheel center to fork face) mm 500 500
9 Ground Clearance(Bottom of mast) mm 140 140
10 Overall Dimension Length to face of fork(Without fork) mm 2700 2700
11 Overall Width mm 1225 1225
12 Mast Lowered Height mm 2125 2125
13 Mast Extended Height(With backrest) mm 4150 4150
14 Overhead Guard Height mm 2090 2090
15 Turning Radius (outside) mm 2445 2445
16 Speed Travel (No load) km/h 19 19
17 Lifting(Full load) mm/s 500 500
18 Max.Gradeability (No load/Full load) % 20 20
19 Tire Front mm 28×9-15-12PR 28×9-15-12PR
20 Rear mm 6.50-10-10PR 6.50-10-10PR
21 Wheelbase mm 1700 1700
22 Service weight kg 4675 4675
23 Battery Voltage/Capacity V/Ah 12/90 12/90
24 Engine Model 　 4JG2PE C490

25 Manufacture 　 ISUZU XINCHAI

26 Rated output/r.p.m. kw 44.9/2450 34.5/2500
27 Rated torque/r.p.m. N·m 186.3/1600-1800 139/1800
28 No.of Cylinder 　 4 4

29 Bore×Stroke mm 95.4×107 86×102
30 Displacement cc 3059 2369
31 Fuel Tank Capacity L 70 60
32 Transmission Type 　 Powershift (Manual) Powershift (Manual)

33 Stage FWD/RVS 　 1/1(2/2) 1/1(2/2)
