Blister Packing Machine
Blister Packing Machine
Blister Packing Machine
Blister Packing Machine (ALU-PVC or AL/AL)
Features
1. DPP-250Z blister packing machine follows ergonomic design principles and is in accordance to the GMP and CGMP structure standards.
2. If there is an operational problem, the machine will automatically stop and display what the problem is.
3. The main motors of our DPP-250Z blister packing machines are equipped with a variable frequency speed controller.
4. Modular-type work stations make the adjustment of work stations clear and easy.
5. A safety enclosure is provided to protect equipment and operators.
6. Independent moulds can be assembled and disassembled easily and conveniently.
Bottom
Our DPP-250Z blister packing machines can be widely used as tablet packing machines, capsule packing machines, and solid packing machines like candy packing machines, biscuit packaging machines, etc.
Parameters of DPP-250DIII Blister Packing Machine
Maximum blanking frequency Alu/ PVC: 50 time/min AL/AL 30time/min
Maximum working capacity Alu/ PVC: 200 blisters/min
AL/AL :120 blisters/min
Stroke ≤130mm (according to customer's request)
Maximum forming area 245x122mm
Maximum forming depth 18mm (upon request)
Packaging material PVC: 260x0.25(0.15-0.5)mm
PTP: 260x0.02mm
Power supply Four wire three phrase 380V 50Hz (220V 60Hz)
Total power 5.7KW
Power of main motor 1.5KW
Air flow ≥0.38m3/min
Dimension of machine(L*W*H) 4200x650x1700mm
Weight 1500kg
Features
1. DPP-250Z blister packing machine follows ergonomic design principles and is in accordance to the GMP and CGMP structure standards.
2. If there is an operational problem, the machine will automatically stop and display what the problem is.
3. The main motors of our DPP-250Z blister packing machines are equipped with a variable frequency speed controller.
4. Modular-type work stations make the adjustment of work stations clear and easy.
5. A safety enclosure is provided to protect equipment and operators.
6. Independent moulds can be assembled and disassembled easily and conveniently.
Bottom
Our DPP-250Z blister packing machines can be widely used as tablet packing machines, capsule packing machines, and solid packing machines like candy packing machines, biscuit packaging machines, etc.
Parameters of DPP-250DIII Blister Packing Machine
Maximum blanking frequency Alu/ PVC: 50 time/min AL/AL 30time/min
Maximum working capacity Alu/ PVC: 200 blisters/min
AL/AL :120 blisters/min
Stroke ≤130mm (according to customer's request)
Maximum forming area 245x122mm
Maximum forming depth 18mm (upon request)
Packaging material PVC: 260x0.25(0.15-0.5)mm
PTP: 260x0.02mm
Power supply Four wire three phrase 380V 50Hz (220V 60Hz)
Total power 5.7KW
Power of main motor 1.5KW
Air flow ≥0.38m3/min
Dimension of machine(L*W*H) 4200x650x1700mm
Weight 1500kg
