Asphalt Mixing Plant(lbj1200)

1
The Cold Aggregate Batching Machine and Feeders

Group of 4 components, the unit capacity of the aggregate hooper is 8M³ (full hooper), the total capacity is 32M³

Adopts imported variable-frequency governor

COntinious dosing belt & driving reduction motor group, group of 4 units

Electric vibrator: 2 units
4 SETS

2
The aggregate collecting belt conveyor

10 X 650 MM, ~ Approx. 16 M
1 SET

3
The aggregate charging belt conveyor, inclined

10 X 650 MM, ~ Approx. 8 M; CAPACITY: 160T/H
1

4
The Drying Drum

Ø1700×7000 MM,

The running speed: 10.9 RPM;

Cylinder on frame,

Rotation drive through electric motor and reduction box,

Heat-preservation is 50mm rack wool and stainless steel
1

5
The burner Group for the Dryer (diesel oil burner)

It is the Chinese manual control or automatic control oil burner
1

6
The mixing tower

THe main tower with the supporting legs, repairing platform and guardail.
1

7
The Hot aggregate elevator

capacity: 120 T/H
1

8
The filler bin: 13 M³;
1

9
The capacity of the filler elevator: 25 T/H
1

10
The Viberating Screen Units

4 grades; capacity: 140T/H
1

11
The hot aggregate storage bin

4 numbers, the total volume is 10.3 M³
1

12
The Weighing Device

The weighing unit for the powder, bitumen and hot aggregate (each has one unit)
3

SETS

13
The mixer

The mixing capacity: 1200 KG/BACH, the motor power: 44KW
1

14
The water filter with water pump and the pipelines
1

15
The Controlling Room

(5M*2.2M*2.5M)
1

16
BItumen Supplying

25t bitumen tanks, two units
2 SETS



17
Bitumen pumps (capacity 15.6 M³/H), pipelines, 3 -way valves
1

18
The thermal oil heater 400.000 Kcal / h
1

19
10T diesel oil tank and 10T heavy oil tank with the pipelines (each has one unit)
2 SETS
