Power Relay T73
Power Relay T73Continuous Selling Item
Power Relay T73
Power Relay
Size:19.0*15.5*15.8 mm
Contact data
Contact Form:1A, 1C
Contact Material:Ag Alloy
Contact Rating
10A250VAC/28VDC
15A125VAC/28VDC
Max.Switching Voltage:250VAC/24VDC
Max.Switching Current:15A
Max.Switching Power:2500VA/420W
Min. Switching Load:5VDC 100mA
Coil Data
Coil Voltage:3~48VDC
Coil Power(mW):360/450/800
General Data
Electrical Lifes(ops.):100,000
Operating Temperature:-40~+85
Terminal Type:PCB Type
Size:19.0*15.5*15.8 mm
Contact data
Contact Form:1A, 1C
Contact Material:Ag Alloy
Contact Rating
10A250VAC/28VDC
15A125VAC/28VDC
Max.Switching Voltage:250VAC/24VDC
Max.Switching Current:15A
Max.Switching Power:2500VA/420W
Min. Switching Load:5VDC 100mA
Coil Data
Coil Voltage:3~48VDC
Coil Power(mW):360/450/800
General Data
Electrical Lifes(ops.):100,000
Operating Temperature:-40~+85
Terminal Type:PCB Type
- Place of Origin:
- Anhui, China
- Brand:
- Tianren
- Unit Price:
- USD 0.15
- Port:
- FOB Shanghai
- Other Price Terms:
- T/T,L/C
- Packing:
- 2000/4000pcs/carton
- Payment Terms:
- L/C;T/T
- Delivery Time:
- 15
- Min Order Quantity:
- 1000pcs
- Standard / Certificates:
- UL,TUV,CQC,ROHS
