WDW Series Electronic Tensile Testing Machine (Single Column)

Main Structure, Function and Application Range ：mainly used in plastic film, stretch film, stretch film, textile fibers, paper, rubber, adhesives, food packaging materials, plastic sheets, wire rope, cell phone cable, wire connector, aluminum foil, stainless steel strip, wire copper wire, stainless steel wire and other small load of the tensile, tear, peel, sealing and other tests. Widely used in factories and mines, metal building materials, aerospace, machinery, wire and cable, rubber, plastics, textiles, household appliances, paper and other industries of material tests and analysis, scientific research institutes, universities, industrial and mining enterprises, technical supervision, inspection arbitration and other departments of the ideal test equipment. Arm stable and reliable host and elegant, tensile journey, stepless speed wide. Large-screen LCD control system based on single chip controller as the core of real-time display test force, displacement, speed indicators, and a test force peak hold function, either manually, or you can set the auto-complete the test pilot Shen Shu, automatic calculation The tensile strength, elongation and other technical indicators. Data query results can be printed.
Prime Technical Parameters:
Model WDW-S01A WDW-S02A WDW-S05A WDW-S1A
Capacity(N) 2~100 4~200 10~500 20~1000
Load Resolution 0.01N
Load Accuracy within ±1%
Displacement Measurement Resolusion 0.01 mm
Speed range of crossbeam 1mm/min~500 mm/min, step less speed regulation and arbitrary setting
Effective Test Space 600 (or 1000) mm
Power 220V±10%, 50Hz
Main configuration AC servo motor and speed adjustment system, precision photoelectric encoder
Load Frame Dimension 400*360*1330 (or 1730) mm
Weight 100kg
