WDW Series Digital Display Electronic Universal Testing Machine （Single Column）

Main Structure, Function and Application Range ：WDW series are suitable for tensile, compression, bending ,cutting shearing and tearing test of rubber, peeling and tearing,plastic, electrical wire and cable, composite, profiled bar, waterproof roll, etc. They are essential testing instruments for quality testing section, university and college, research institution and industrial and mining enterprise.This machine equips alternating servo motor for driving crossbeam and imported photoelectric encoder for displacement measure. The controller adopts flush type monolithic computer structure and is equipped multitask operating system and built-in powerful test control software, which includes the test system with measuring, controlling, calculating and saving functions.
Technical Parameters:
Model WDW-S1 WDW-S2 WDW-S3 WDW-S5
Capacity 0.02～1kN 0.04～2kN 0.06~3kN 0.1~5kN
Load Accuracy within ±1%
Displacement Resolution 0.01 mm
Speed Range 1 mm/min～500 mm/min, step less speed regulation and arbitrary setting
Test Space 600(or 900)mm
Power 220V±10%, 50Hz
Main configuration AC servo motor and speed adjustment system, precision photoelectric encoder.
Dimension 425*350*1350 (or 1650) mm
