Gravity Casting Machine
Gravity Casting MachineItem Code / Model Number:
Gravity Casting Machine
Gravity Casting Machine of Type DL-450-B
Main specifications and technical parameters
1. Biggest Size of The Mould ø450 mm
2. Heaviest Weight of The Mould 130 kg
3. Largest Merger Distance ≤250 mm
4. Hydraulic Pressure 40-60 KPa
5. Angle of Injecting 0°- 90°
6. Frontal Casting Angle 0°- 110°
7. Hydraulic Lube 163 L
8. Net Weight of The Whole Machine 1750 kg
9. Size of Appearance of Machines(L*W*H) 2250*2160*1560 mm
10. Installing Top Core Available Itinerary of Top Core 20 mm
11. Total Power 5.5 kw
Main specifications and technical parameters
1. Biggest Size of The Mould ø450 mm
2. Heaviest Weight of The Mould 130 kg
3. Largest Merger Distance ≤250 mm
4. Hydraulic Pressure 40-60 KPa
5. Angle of Injecting 0°- 90°
6. Frontal Casting Angle 0°- 110°
7. Hydraulic Lube 163 L
8. Net Weight of The Whole Machine 1750 kg
9. Size of Appearance of Machines(L*W*H) 2250*2160*1560 mm
10. Installing Top Core Available Itinerary of Top Core 20 mm
11. Total Power 5.5 kw
- Place of Origin:
- China
- Brand:
- De Lin
- Unit Price:
- USD 24233
- Price Terms:
- FOB Xiamen
- Packing:
- wooden case
- Payment Terms:
- L/C;T/T
- Delivery Time:
- 30 days
- Min Order Quantity:
- 1piece
- Keywords:
- gravity casting, brass casting, die casting
