Motors

Specifications

Stator Diameter ....................................14 mm(3.15 in)
Stator Thickness ....................................10 mm(1.57in)
No.of stator Arms .......................................................3
No.of stator Poles ......................................................2
Motor Wind .............................................62 Turn Delta
Motor Wire .......................................3-Strand 0.19 mm
Motor Kv ................................................6000 RPM/Volt
NO-Load Current(IO/6V) ..............................0.38 Amps
Motor Resistance(RM) ................................0.265 Ohms
Max Continuous Current ...................................8 Amps
Max Continuous Power ..................................57 Watts
Weight ..........................................19.8 Grams (0.59oz)
Outside Diameter ............................15.99 mm (0.79 in)
Shaft Diameter ..................................1.98mm (0.08 in)
Body Length .....................................29.8 mm (1.17 in)
Ovrall Shaft Length ...............................37 mm (1.46in)

Weight including packaging

40g

Full Dimension

View Scorpion Z-1410-6000KV Full Dimension
