Pancake Slip Ring
Pancake Slip Ring, PSR-P96Item Code / Model Number:
PSR-P96
Pancake Slip Ring
Product introduction
PSR-PS is a pancake type slip rings that with any size through -bore and 10mm Min thickness , low torque , exactly preformace for transfer signal and power wih rotation . Use special vaccum infusion technical, use precious metal as contact material , enclose type and serperate type is available, to make sure it's transferand rotary capability.
Specification
Rated voltage: 240VAC
Rated current: 2A/way
Through bore: 96mm
Outer Diameter: 166mm
Thickness:10mm
Circuit No: 1-26 way
Speed:300 Rpm
Feature
1) Compact design with small size, can meet harsh space requirements;
2) Moudle design, meet higher requirement such as high current, high speed and outline;
3) Diversify shape and support more installing requipment;
4) Support signal, power and it's combined transmission.
Typical Application
1) Satellite receiver
2) Electrical test equipment
3) Test rotary table
4) Radar
Environment
Operation temperation: -40℃~60℃
Mechanical vibration: MIL-SID-810E
Relative humidity: 60%
PSR-PS is a pancake type slip rings that with any size through -bore and 10mm Min thickness , low torque , exactly preformace for transfer signal and power wih rotation . Use special vaccum infusion technical, use precious metal as contact material , enclose type and serperate type is available, to make sure it's transferand rotary capability.
Specification
Rated voltage: 240VAC
Rated current: 2A/way
Through bore: 96mm
Outer Diameter: 166mm
Thickness:10mm
Circuit No: 1-26 way
Speed:300 Rpm
Feature
1) Compact design with small size, can meet harsh space requirements;
2) Moudle design, meet higher requirement such as high current, high speed and outline;
3) Diversify shape and support more installing requipment;
4) Support signal, power and it's combined transmission.
Typical Application
1) Satellite receiver
2) Electrical test equipment
3) Test rotary table
4) Radar
Environment
Operation temperation: -40℃~60℃
Mechanical vibration: MIL-SID-810E
Relative humidity: 60%
- Place of Origin:
- China
- Brand:
- PANLINK
- Unit Price:
- USD 2
- Price Terms:
- FOB shenzhen
- Packing:
- 8pcs each carton
- Payment Terms:
- L/C;T/T
- Delivery Time:
- 10-15 days
- Min Order Quantity:
- 2
- Keywords:
- slip ring, connectors, pancake slip ring
