open frame lcd monitor with 10.4 inch diagonal size for industrial control equipment
open frame lcd monitor with 10.4 inch diagonal size for industrial control equipment, ORX104OPAU08-T1Item Code / Model Number:
ORX104OPAU08-T1
open frame lcd monitor with 10.4 inch diagonal size for industrial control equipment
This open frame LCD display can be used for industrial control, NC equipment, medical equipment, financial equipment, vehicle navigation and the yacht navigation.It is easily integrated into your relevant equipment, the design, the dimension, the material, the signal connector etc. are can be customized, we can provide OEM service.
Features:
10.4 inch diagonal size
TN dispaly mode
800(RGB)x600(VGA) dot resolution
211.2mmx158.4mm active display area
800:1 contrast ratio
400cd/m2 Brightness
White LED lamp type
Viewing angle (L/R/U/D) is 80/80/60/80
Signal connector is DVI or vga
power consumption is DC 12V
The dimension(L/W/H) is 310mmx197mmx50.5mm
Features:
10.4 inch diagonal size
TN dispaly mode
800(RGB)x600(VGA) dot resolution
211.2mmx158.4mm active display area
800:1 contrast ratio
400cd/m2 Brightness
White LED lamp type
Viewing angle (L/R/U/D) is 80/80/60/80
Signal connector is DVI or vga
power consumption is DC 12V
The dimension(L/W/H) is 310mmx197mmx50.5mm
- Place of Origin:
- China
- Brand:
- ORX
- Packing:
- Anti-static bag
- Payment Terms:
- T/T
- Delivery Time:
- 28 days
- Min Order Quantity:
- 1 piece
- Standard / Certificates:
- CE FCC ROHS
- Keywords:
- lcd dispaly, lcd monitor, lcd screen
