Lm.r33.a Lcd/led Controller Board
Lm.r33.a Lcd/led Controller Board, LM.R33.AItem Code / Model Number:
LM.R33.A
Lm.r33.a Lcd/led Controller Board
Specification:
1. Support Resolutions:
VGA:640*480 SVGA:800*600
XGA:1024*768 SXGA+:1680*1050
2. Interface:
RGB input: 60Hz AT VGA SVGA XGA WXGA+ SXGA+
72Hz AT VGA SVGA
75Hz AT VGA SVGA XGA
AUDIO output: acoustic power 2*1W/8Ω
3. Panel Voltage:3.3V/5V/12V(option)
4. Panel interface:Single/Double LVDS, TTL 45PIN+30PIN FFC 30PIN+40PIN
5. Voltage requirement:DC/12V
6. Working environment:Relative humidity<80%,0-40℃
stand-by power consumption:<1W
7. ODS Language: Simplified Chinese Traditional Chinese, Korean, French , Italian, Spanish and Portuguese
1. Support Resolutions:
VGA:640*480 SVGA:800*600
XGA:1024*768 SXGA+:1680*1050
2. Interface:
RGB input: 60Hz AT VGA SVGA XGA WXGA+ SXGA+
72Hz AT VGA SVGA
75Hz AT VGA SVGA XGA
AUDIO output: acoustic power 2*1W/8Ω
3. Panel Voltage:3.3V/5V/12V(option)
4. Panel interface:Single/Double LVDS, TTL 45PIN+30PIN FFC 30PIN+40PIN
5. Voltage requirement:DC/12V
6. Working environment:Relative humidity<80%,0-40℃
stand-by power consumption:<1W
7. ODS Language: Simplified Chinese Traditional Chinese, Korean, French , Italian, Spanish and Portuguese
- Place of Origin:
- China
- Brand:
- Vantron
- Unit Price:
- USD 5-9
- Price Terms:
- FOB Shenzhen
- Packing:
- 1pcs/blister bag
- Payment Terms:
- T/T;Cash
- Payment Remarks:
- Paypal,western union,bank transfer
- Delivery Time:
- 3 days
- Min Order Quantity:
- 10pcs
- Standard / Certificates:
- CE,RoHS
- Keywords:
- lmr33a, lcd controller board, ttl lvds driver board
