Automobile Coating Thickness Meter
Automobile Coating Thickness Meter, ZL-1201Item Code / Model Number:
ZL-1201
Automobile Coating Thickness Meter
1.Application: used for measuring thickness and corrosion of pressure vessels,chemical equipment,boilers,oil storage tanks,etc.in industries of petroleum,shipbuilding,power station,and machine manufacturing.
2.Parameter:
2.1 Operating principle:magnetic induction/eddy current (F/NF);
2.2 Measuring range:0-1250um/0-50mil;
2.3 Resolution:1/10;
2.4 Accuracy:±1-3%n or ±2.5um;
2.5 Min. measuring area: 6mm;
2.6 Min. sample thickness: 0.3mm;
2.7 Battery indicator:low battery indicator;
2.8 Power supply:4x1.5V AAA(UM-4)battery;
2.9 Operating conditions:0-+45℃(32℉-104℉),≤90%RH;
2.10 Dimensions:126x65x27mm;
2.11 weight:81g(not including battery)
2.Parameter:
2.1 Operating principle:magnetic induction/eddy current (F/NF);
2.2 Measuring range:0-1250um/0-50mil;
2.3 Resolution:1/10;
2.4 Accuracy:±1-3%n or ±2.5um;
2.5 Min. measuring area: 6mm;
2.6 Min. sample thickness: 0.3mm;
2.7 Battery indicator:low battery indicator;
2.8 Power supply:4x1.5V AAA(UM-4)battery;
2.9 Operating conditions:0-+45℃(32℉-104℉),≤90%RH;
2.10 Dimensions:126x65x27mm;
2.11 weight:81g(not including battery)
- Place of Origin:
- China
- Brand:
- Zhongli
- Unit Price:
- USD 600
- Price Terms:
- FOB Shenzhen
- Packing:
- Automobile Coating Thickness Meter is packed in a polybag, then packed as export safety wooden case
- Payment Terms:
- L/C;D/A;T/T;D/D;D/P
- Delivery Time:
- 7-15 days
- Min Order Quantity:
- 1pcs
- Standard / Certificates:
- CE
- Keywords:
- coating thickness meter, thickness meter, coating thickness tester
