aerosol fire suppression system ZY-30E

AEROSOL FIRE SUPPRESSION SYSTEM
Requirement of Working Environment
Temperature Range: -20℃~ +55℃
Relative Humidity: ≤95%
Working Principle
The fire alarm controller or gas fire extinguishing control to detect signals, when detect out there is a fire, the output signal to start new type S aerosol fire extinguishing systems, after the type S aerosol fire extinguishing system receive start signal, the internal flame retardant are activated, quickly produce fire extinguishing gases and discharging, quickly put out the fire.
Extinguishing Time ≤40s
Spout Temperature ≤200℃(5mm distance from outlet）
Shall Surface Temperature ≤100℃
Actual Extinguishing Efficiency ≤100g/m3
Start Voltage DC3~24V/AC3~220V
Minimum Starting Current ≥250mA/5ms
Maximum Safety Current ≤150mA/5min
Vent and People Safety Distance 1.5m
Fire Fighting Jet and Objects Safety Distance 0.3m
Connection Series
Use Life(Life-Span) 10 years
Fire Suppression Type A,B,C,E
