Notebook Camera Module (vga)

Notebook Camera Module, PCB + Connector, VGA

This model is a camera module supporting the VGA-COMS sensor.It has USB2.0 High speed Interface.And has the capability of transferring uncompressed data in VGA size at 30fps.

In addition,it uses a low-cost and high-performance PC Camera processor developed by SONIX; the SN9C230 can provide high quality video streaming,and is fully compliant with USB Video Class1.0 standard; this module can update firmware online without change the hardware by using USB interface.

This model supports the USB-Video-Class drive provided by Microsoft as capture driver so it can operate on WindowXP-SP2 without installing another capture drive,and also can operate on Windows-Vista.




OVERVIEW

This model is a camera module supporting the VGA-COMS sensor.It has USB2.0 High speed Interface.And has the capability of transferring uncompressed data in VGA size at 30fps.

In addition,it uses a low-cost and high-performance PC Camera processor developed by SONIX; the SN9C230 can provide high quality video streaming,and is fully compliant with USB Video Class1.0 standard; this module can update firmware online without change the hardware by using USB interface.

This model supports the USB-Video-Class drive provided by Microsoft as capture driver so it can operate on WindowXP-SP2 without installing another capture drive,and also can operate on Windows-Vista.



Sensor: OV7670 CMOS sensor

Pixels: 0.3mega (VGA)

Top resolution: 640*480 dpi

Lens type: 1/6 inch

FOV: 58 degree

Interface: USB2.0/1.1

AGC/AEC/WHITE BALANCE: Automatic adjust

Size: 8mmX60mmX4.2mm(customize available)
