Eco Solvent Printer

Product Model
SJ-1801
Printing Technology
Epson 5th Micro Piezo printhead Technology
Number of Printhead
1 Head / 1440 Nozzles
Ink Colors
4 colors / (C,M,Y,K)
Printhead Height
Adjustable 2~5mm
Resolution
1440DPI
Ink Droplet Size
1.5~21pl
Printing Width
1800mm(max)
Speed
High Speed Mode: 720 x 720dpi 12㎡/hr
Standard Mode: 720 x 1080dpi 7.7 ㎡/hr
Photo Mode: 720 x 1440dpi 5.7 ㎡/hr
Heating System
The heaters for front and center platform separately, PID temperature control
Drying System
External Fan
Media
Width:1900mm (max media width)
Media feeding mode: Automatic feeder
Automatic take up (optional)
Self-adhesive paper, PVC, Mesh fabric, Textile, PVC flex banner, Vinyl, Paper, Fabric, Leather and etc.
Ink
T5.5 ECO Solvent Pigment Ink
T5.5 ECO Solvent Dye Ink
ST5.5 Water Based Dye Ink

Ink Supply Pipe based continues ink supply / Ink Cartridge 8 x 350ml
RIP Software
Iprint 3.0(equipped) , Maintop(optional)

PostScript file process(optional)

Printing Interface
USD2.0 , RS232

Operating System
Windows XP

Voltage
AC 220V~240V 50/60HZ or AC 110V~120V 50/60HZ

Machine Dimension
L2840mm x W900mm x H1250mm(bracket included) 220KG
Package Dimension
L3000mm x W930mm x H730mm(bracket included) 300KG
Working Environment
Temperature 20℃~25℃ Humidity 40~70% Non-condensing
