All In One Box Camera
All In One Box Camera, DF-628Item Code / Model Number:
DF-628
All In One Box Camera
1. Electronic shutter speed changeable
2. BLC area selectable
3. AGC changeable
4. White balance mode selectable
5. Zoom Lens
6. With mirror function
7. Motion detection on/off
Model: DF-628CD DF-628HD
Image Sensor: 1/4” Sony Super HAD CCD 1/3” Sony Super HAD CCD
Pixels(H×V): P:752(H) ×582(V) N:768(H) ×494(V)
Scanning System: PAL/NTSC
Horizontal Resolution: 480 TVL 600TVL
Synchronization: Internal
Minimum Illumination: 0.05Lux/F1.2
Backlight Compensation: Automatic
Electronic Shutter: 1/50(60)~1/100,000 Sec.
White Balance: Automatic
Lens: F=3.9-85.8mm
Optical Zoom: 22X
S/N Ratio: ≥48DB
Gamma Correction: 0.45
Video Output: 1.0Vp-p/75Ω
Operation Temperature: -20~55℃
Power Supply: DC 12V, 1,000mA
Dimensions (mm): 107×58×71mm
Weight (g): 420g
2. BLC area selectable
3. AGC changeable
4. White balance mode selectable
5. Zoom Lens
6. With mirror function
7. Motion detection on/off
Model: DF-628CD DF-628HD
Image Sensor: 1/4” Sony Super HAD CCD 1/3” Sony Super HAD CCD
Pixels(H×V): P:752(H) ×582(V) N:768(H) ×494(V)
Scanning System: PAL/NTSC
Horizontal Resolution: 480 TVL 600TVL
Synchronization: Internal
Minimum Illumination: 0.05Lux/F1.2
Backlight Compensation: Automatic
Electronic Shutter: 1/50(60)~1/100,000 Sec.
White Balance: Automatic
Lens: F=3.9-85.8mm
Optical Zoom: 22X
S/N Ratio: ≥48DB
Gamma Correction: 0.45
Video Output: 1.0Vp-p/75Ω
Operation Temperature: -20~55℃
Power Supply: DC 12V, 1,000mA
Dimensions (mm): 107×58×71mm
Weight (g): 420g
- Place of Origin:
- China
- Brand:
- Dfd
- Payment Terms:
- T/T
- Delivery Time:
- 5-7 days
- Min Order Quantity:
- 100 pieces
- Standard / Certificates:
- EC, FCC
- Keywords:
- cctv cameras, box camera, security products
