Sell Metallized Polypropylene Film Capacitor For AC Motors

■Reference Standard
GB/T3667-2005（IEC60252/UL-810）
■Structures
Material: Polypropylene film
Electrode: Metallized Vacuum Evaporated Layer
(With complexing jumbo-size Zinc and Aluminum )
Case: PBT Fire-proof plastic box
Encapsulation: Fire-proof Epoxy Resin
Pin: CP leads or PVC Electronic Treads or Terminals
■Using area
Used for the Starting and Working of Single Phase
Motor with 50HZ/60HZ frequency AC in Power Supplying.
■Features:
Box type provides the identical outer appearance
with good self=healing effect .Very low loss at
high frequency,With High insulation resistance
and Long life
■The file No. of UL:E305198
■Specifications
Climate Conditions: -40--+70℃
Rated Voltage: 250VAC;350VAC;400VAC;450VAC
Capacitance Range: 0.5µF--10µF
Capacitance Tolerance:（±5%）（±10%）(+10/-5)%
