Waterproof Gps Car Tracker / Gps Motorcycle Tracker / Long Life Battery Tracker

SpecificationsGPS/GPRS/SMS asset tracker
GPS heavy equipment tracker
GPS motorcycle tracker
waterproof dust proof
optional remote control

GENERAL DESCRIPTION

The MC500 is a poweful but small sized, waterproof, dust proof GPS/GPRS/GSM tracking system specially designed for asset,motorcycle and equipment tracking.It has built-in 2800mA battery for standalone long time operation. Built in GPS antenna, Built in GPRS antenna, Also works with 12V external power.It has rugged design with 100% waterproof case and vibration resistant. Easy mounting with optional magnets.



MC300 works with our web based tracking software EX-OR1000, users can host our server or we supply a complete software packet.



FUNCTIONALITY
- Standard tracking reports by:
location, speed, time, direction,unit status
- GPS and GSM dual positioning functions.
- Embedded GSM and GPS antenna.
- Periodic reporting using GPRS or SMS
- Remote site continuous reporting
- Geofence reporting
- Anti-theft reporting to be set from the

internet or on the device
- Voice monitoring function
- Fast GPS and GSM signal checking using
test button on the device
- Optional remote control for arm & disarm
- Optional 5600Mah external battery

- Motion sensor to detect any movement
- SOS emergency report
- Remote speed limit setting
- Speeding report function
- LED lights for GPS/GPRS POWER status.
- Super sensitivity GPS module
- Two tri-band GSM/GPRS module
- Low battery indicator and SMS reporting
- Standby and charging indicator
- Using SIM card phonebook to set reporting
number and parameters to make the
interface easy
- 100% waterproof, vibration proof, rubber
covering with magnetic mount for vehicle
tracking
- LED light for park Geofence setting/release
- Low power consumption with large battery
capacity to
- Long standby time for more than 3 days.
- Home/Car charger is available.




SPECIFICATION
- Size: 80mm(L) x 45mm(W) x 31mm(H)
- Weight: 100g
- GSM frequencies:
SIEMENS MC55: 900/1,800/1,900 MHz
SIEMENS MC56: 850/1,800/1,900 MHz
- Frequency of GPS reception: 1575.42 MHz
- Channels of GPS reception: 16 channels
- GPS sensitivity: -158 dBm
- I/O: Power input, Optional engine cut output
- Warm-up time: 70 seconds
- Storage temperature: -10C to +60C
- Power: 3.7 to 4.2 VDC
- Power consumption for standby: 50mA
- Power consumption
GSM communication: 250 mA
- Standby time: 3 days (for GPS always on)
- Battery capacity: 2,800 mah

- Optional battery 5400mah ( last for 10 days in standby mode)

- Optional magnet for easy mounting
