LED Driver
LED Driver, GD-L32B SeriesItem Code / Model Number:
GD-L32B Series
LED Driver
LED Drivers
GD-L32B Series ( Size: L124mm x W34mm x H22mm )
Input Voltage: AC220-240V
Constant Current 350mA --- Output : 9W / 12W / 15W
Constant Current 700mA --- Output : 9W / 12W
Constant Voltage : 1. 12V 1-12W / 2. 24V 1-12W
Certificate: CE , RoHS
Overload Protection , Short circuit Protection , Over Temperature Protection
GD-L32S series ( Size: L124mm x W34mm x H22mm )
Input Voltage: AC220-240V
Constant Current 350mA --- Output : 10W / 15W
Constant Current 700mA --- Power : 18W
Constant Voltage : 1. 12V 1-12W / 2. 24V 1-12W
PF : 0.9
Certificate: CE , RoHS
Overload Protection , Short circuit Protection , Over Temperature Protection
GD-KDL / VDL32B series ( Size: L124mm x W34mm x H22mm )
Input Voltage: AC220-240V
Constant Current 350mA --- Output : 10W
Constant Current 700mA --- Output : 15W
Certificate: CE , RoHS
Dimmable Brightness : 1. 0-10V dimmer , 2. Key dimmer 3. Touch dimmer
Overload Protection , Short circuit Protection , Over Temperature Protection
GD-L32B Series ( Size: L124mm x W34mm x H22mm )
Input Voltage: AC220-240V
Constant Current 350mA --- Output : 9W / 12W / 15W
Constant Current 700mA --- Output : 9W / 12W
Constant Voltage : 1. 12V 1-12W / 2. 24V 1-12W
Certificate: CE , RoHS
Overload Protection , Short circuit Protection , Over Temperature Protection
GD-L32S series ( Size: L124mm x W34mm x H22mm )
Input Voltage: AC220-240V
Constant Current 350mA --- Output : 10W / 15W
Constant Current 700mA --- Power : 18W
Constant Voltage : 1. 12V 1-12W / 2. 24V 1-12W
PF : 0.9
Certificate: CE , RoHS
Overload Protection , Short circuit Protection , Over Temperature Protection
GD-KDL / VDL32B series ( Size: L124mm x W34mm x H22mm )
Input Voltage: AC220-240V
Constant Current 350mA --- Output : 10W
Constant Current 700mA --- Output : 15W
Certificate: CE , RoHS
Dimmable Brightness : 1. 0-10V dimmer , 2. Key dimmer 3. Touch dimmer
Overload Protection , Short circuit Protection , Over Temperature Protection
- Place of Origin:
- China
- Brand:
- Gedi Lighting
- Other Price Terms:
- EXW
- Packing:
- 1 piece 1 case , cases in 1 carton
- Payment Terms:
- L/C;T/T
- Delivery Time:
- 30 days days
- Min Order Quantity:
- 200 pcs
- Standard / Certificates:
- CE , RoHS
- Keywords:
- led driver, led power supply, led lamps driver
