Sell 24W AC/DC Adapter Swithcing power supply

Product Description

1, technical information:
Plug-In Mains Connector EU
Input Condition AC100-240V 50/60 Hz
Input Rated Voltage 100Vac-240Vac
Input Voltage Range 90Vac-264Vac
Input Rated Frequency 50/60Hz
Input Frequency Range 47Hz-63Hz
Input Current 0.35A Max
Input Inrush Current 30A Max
Rated Output Voltage & Current 24V & 1.0A
Output power 24W Maximum
Output Line Regulation ± 1%
Output Load Regulation ± 5%
Output Over Shoot 10% Maximum
Output Ripple And Noise 100mVp-p Max
Output Rising Time 20ms Maximum At 115Vac
Output Hold up Time 10ms Minimum At 230Vac
No Load Power Consumption 0.3W Max At 115Vac/230Vac
Efficiency Conform to Level V (CEC/ERP/MEPS)
Protection OCP OVP OTP OLP
Dielectric Withstand Voltage 3KV 5mAnbsp; 60s
Leakage Current 0.25 mA At 230Vac
DC Plug Specification According to the customer' s requirements
Operating Temperature Range 0--40 degrees
Storage Temperature Range -20--60 degrees


2,application :

Consumer Electronics Products, Toys, DVD/ MP3/MP4, IP camera, Antenna Communications products, Wireless AP, Wireless Router, IP phones, Security Systems, Set-top boxes, Health care electronics, LED lighting products and so on.


3, reliability:

Fault-free time: 50, 000 hours, -25 degree celsius (according to the mil-HD-217 standard)


4,Protection

Short circuit protection
Over voltage protection
Over current protection
Thermal shutdown capability
5, SAFETY APPROVALS:
UL 60950-1,2nd Edition,2011-12-19
UL 1310 Sixth Edition, Dated August 26,2011
CSA C22.2 No. 60950-1-07,2nd Edition,2011-12-19
CAN/CSA-C22.2 No.223-M91:1991
EN 60950-1:2006+A11:2009
EN 60950-1:2006+A11:2009+A1:2010
EN 60950-1:2006+A11:2009+A1:2010+A12:2011
CE(Low Voltage Directive)
IEC 60950-1:2005+A1:2009
AS/NZS 60950.1:2011 Amendment 1
PSE IEC60950
GB4943.1-2011
