Sell Automatic AOI inspection machine, HY-D520

model On-line dip detection AOI HY-D520 Appearance specification operational power supply AC220V+_10% 50/60HZ 1KW Shape size (length * width * height) 1130*1180*1560mm weight 700KG Image identification unit Image identification unit RGB + W four - color ring light source Image identification mode Contour operations, color feature extraction, gray-scale operations, image comparisons, etc. camera Imported custom 200W pixel camera X-Y pixel resolution 15/20um optional Z axis resolution =35mm Maximum allowable plate bending 2% or 5 mm of PCB diagonal length The size of the check window FOV 30*2mm Minimum size of inspectable parts 01005/0201 Agency department Detectable PCB allowable area maximum 50mm*50mm minimum 460mm*510mm PCB thickness range =6mm Maximum PCB weight 3KG PCB holding end reservation gap 3.5mm PCB transmission speed 750mm/s(MAX) track width modulation Manual / automatic Software and hardware operating system (OS) Windows7 Operation interface Chinese and English interface optional Master controller ( CPU ) I7CPU hard disk 500G DRAM capacity 4G memory indicator Acer 21.5 inch inspection item Tin paste printing: have or not, offset, less tin, more tin, open circuit, even tin, pollution, etc. Part defects: missing parts, offsets, skew, steles, measuring stands, turning pieces, wrong parts（OCV），breakage, reverse, etc. Solder joint defects: tin more, tin less, virtual welding, even tin, copper foil pollution, etc. NG marking OKP NG signal, substrate ID, substrate name, component name, defect Picture, Bad Point coordinates Program writing requirement data Support common component library and CAD data import Data output format Automatic Generation of Statistical Analysis SPC and data report form Offline editing software CAD Characteristics (special functions) Select a pair of bad points to achieve one-to-one accurate marking (built-in or external marking, inkjet function)
