High TG Printed Circuit Board

High TG PCB China Manufacturer - JingHongYi PCB (HK) Co., Limited.

Blank PCB, High TG PCB, High TG Circuit Board, High TG Printed Circuit Board

we are specialized manufacturers from China, High TG PCB, High TG Circuit Board, High TG Printed Circuit Board suppliers/factory, wholesale high-quality products of High TG Circuit Board R & D and manufacturing, we have the perfect after-sales service and technical support. Look forward to your cooperation!

Our high tg PCB products

High Temperature PCB fr4
https://www.pcbjhy.com/high-tg-pcb/56712944.html

High TG PCB 6 Layer
https://www.pcbjhy.com/high-tg-pcb/56712945.html

High Tg Printed Circuit Board
https://www.pcbjhy.com/high-tg-pcb/56712978.html

High Tg Circuit Boards
https://www.pcbjhy.com/high-tg-pcb/56712981.html

Fr4 High Tg PCB
https://www.pcbjhy.com/high-tg-pcb/56724352.html

High TG PCB Board
https://www.pcbjhy.com/high-tg-pcb/56712943.html

In recent years, there are more and more customers request to manufacture PCB with high Tg.

If you work with Printed Circuit Boards in your industry, you may or may not be familiar with the high-TG PCBs. Since the effective operation of your printed circuit boards is so important to your business, it may be in your best interest to understand a little bit more about high-TG printed circuit boards.

What Is High-TG?

Tg means Glass Transition Temperature. As flammability of Printed Circuit Board (PCB) is V-0 (UL 94-V0), so if the temperature exceeds designated Tg value, the board will change from glassy state to rubbery state and then the function of PCB will be affected.

If the working temperature of your product is higher than normal (130-140C), then have to use high Tg material which is > 170C. and popular PCB high value is 170C, 175C, and 180C. Normally the PCB Tg value should be at least 10-20C higher than working temperature of the product. If you 130TG board, the working temperature will be lower than 110C; if use 170 high TG board, the maximum working temperature should be lower than 150C.
